2.8 ~ 12mm, AF automatic focusing and motorized zoom lens
DORI Distance
Lens (mm)
Detect (m)
Observe (m)
Recognize (m)
Identify (m)
2.8
63
25.2
12.6
6.3
12
270
108
54
27
Angle of view (H)
91.0° ~ 27°
Angle of View (V)
54.4° ~ 13.7°
Angle of View (O)
118.3° ~ 33.2°
Adjustment angle
Pan: 0° ~ 360°
Tilt: 0° ~ 90°
Rotate: 0° ~ 360°
Shutter
Auto/Manual, 1 ~ 1/100000s
Minimum Illumination
Colour: 0.005Lux (F1.4, AGC ON) 0Lux with IR
Day/Night
IR-cut filter with auto switch (ICR)
Digital noise reduction
2D/3D DNR
S/N
>52dB
IR Range
Up to 30m (98ft) IR range
Defog
Digital Defog
WDR
120dB
Video
Video Compression
Ultra 265, H.264, MJPEG
H.264 code profile
Baseline profile, Main Profile, High Profile
Frame Rate
Main Stream: 4MP (2592*1520), Max 20fps; 4MP (2560*1440), Max 25fps; 3MP (2048*1520), Max 30fps; Sub Stream: 2MP (1920*1080), Max 30fps; Third Stream: D1 (720*576), Max 30fps
HLC
Supported
BLC
Supported
9:16 Corridor Mode
Supported
OSD
Up to 8 OSDs
Privacy Mask
Up to 8 areas
ROI
Up to 8 areas
Motion Detection
Up to 4 areas
Smart
Behavior Detection
Intrusion, cross line, motion detection
Intrusion
Enter and loiter in a pre-defined virtual region
cross line
Cross a pre-defined virtual line
motion detection
Moving within a pre-defined virtual region
Recognition
Face detection, Audio detection
Intelligent Identification
Defocus, Scene Change, Object Left, Object Moving
Statistical Analysis
People counting
General Function
Watermark, IP Address Filtering, Tampering Alarm, Access Policy, ARP Protection, RTSP Authentication, User Authentication
